PICMG1,3 LGA1151 Intel® 6th Gen. Core™ i7/i5/i3/Pentium®/Celeron® CPU per Intel® Q170, DDR4, VGA/IDP, Dual Intel® PCIe GbE, USB3.0, SATA 6Gb/s, PCIe mini, mSATA, HD Audio, iAMT and RoHs
Specification:
CPU: LGA 1151 socket supports Intel® 6th/7th generation Core™ i7/i5/i3, Pentium® or Celeron® processor
Chipset: Intel® Q170
Memory: Four 288-pin 1866/2133 MHz dual-channel unbuffered DDR4 DIMMs up to 64 GB
Storage:
6 x SATA :RAID 0/1/5/10 supported
1 x mSATA :SATA & USB signal
Display Output:
1 x VGA :up to 1920x1200@60Hz
1 x iDP :for HDMI™, LVDS, VGA, DVI and DisplayPort (up to 3840x2160@60Hz)
Ethernet: 2 x LAN
LAN1: Intel® I219LM Clarkville-V with Intel® AMT 11.0 supported;
LAN2: Intel® I210 PCIe controller;
Audio: Description: Support 7.1 channel HD audio by IEI AC-KIT-892HD kit
I/O Interface:
2 x Internal RS-232 :2x5 pin, P=2.54
2 x Internal RS-232/422/485 :2x5 pin, P=2.54
2 x External USB 3.2 Gen1x1
7 x Internal USB 2.0 :1 X 180° Type-A,6 X 2x4 pin, P=2.54
2 x Internal USB 3.2 Gen1x1 :2x10 pin
1 x LPT :2x13 pin
Expansion:
16-lane PCIe link from CPU via golden finger:
Supports one PCIe x16, or two PCIe x8, or one PCIe x8 + two PCIe x4 on the backplane (configured via BIOS);
4-lane PCIe link from PCH via golden finger:
Supports four PCIe x1 slots or one PCIe x4 slot on the backplane (configured via BIOS switch);
4 x PCI Slot
1 x PCIe mini Card Slot :Full/Half-size
TPM: 2x10 pin
Power Consumption:
5V@3.12A, 12V@6.85A, 3.3V@1.13A, 5VSB@0.15A
(Intel® Core™ i7-6700K 4.0GHz CPU with 64GB (16GB x 4) 2133 MHz DDR4 memory)
Certification:
,
compliant
Packing list:
- 1 x PCIE-Q170 single board computer
- 1 x Mini jumper pack
- 1 x SATA cable
- 1 x QIG
Certification: , compliant
Customs Tariff (HS ) code : 84733020
