Lex Slim 15" ( 4:3 ) Panel PC with Intel® Elkhart Lake ATOM x6413E Quad Core 3.0 GHz CPU, Resistive Touch Screen
Lex MB: 3I640CW-E13
Chipset: Intel® Elkhart Lake SoC
Memory: 1 x DDR4 SODIMM, Max. 32GB
Storage: SSD, M.2
2 x 2.5GbE, 6 x COM, DVI, HDMI, 4 x USB, Audio
Wide Range 9~36V DC input
ABS front frame + Aluminum housing
Max. Resolution: 1280 x 1024
Power: +9~36V DC input
Mounting: Support Panel Mount / Wall mount, VESA mount & Stand (optional)
Expansion slots
- 1 x M.2 B Key Type3042 (SATA / USB 2.0 / USB 3.0)
- 1 x M.2 B Key Type2242 (PCIe x2 / USB 2.0), support NVMe
- 1 x Mini PCIe (USB 2.0 / PCIe)
- 1 x Mini SIM
I/O ports
- Network: 2 x Intel 2.5 GbE
- USB: 2 x USB 3.0, 2 x USB 2.0 ; 2 x USB 2.0 (optional)
- Serial ports 2 x RS232 / 422 / 485, 4 x RS232
- Display 1 x DVI, 1 x HDMI
- HD Audio Line-out / Mic-in
OS Support:
- Windows® 11 IOT , Windows® 10 IOT
- Ubuntu 22.04 above, Fedora 36 above
Power Adapter: 60 Watts AC-DC Ø 5.5 / Ø 2.5
Accessories:
- German Power cord
- 60 Watts AC power adapter
- Touch Pen
- Panel Mount accessories
Customs Tariff Nr.: 84714100
Certification:
,
