TT1-BTJ022
TT1-BTJ022  TT1-BTJ022  TT1-BTJ022  TT1-BTJ022  TT1-BTJ022

TT1-BTJ022

  • Brand: Lex
  • Product Code: Lex_sys
  • Availability: Lead time 2 weeks


TWITTER 3I380D, Lex Twitter fanless chassis Barebone ,Lex MB 3I380D-D90 ( TT2516-00F-9670 ), Intel J1900 CPU, 4LAN, COM, HDMI, SODIMM

Specification:

CPU: Intel® Bay Trail J1900 2.0 Ghz (Quad Core)
Chipset: Intel® Bay Trail SoC
Memory: 1 x DDR3L SODIMM socket, Max. 8GB (3I380D-D90)
Storage: mSATA, HDD / SSD*
Expansion slots:

  • 1 x Full-size Mini PCIe (USB)
  • 1 x Full-size Mini PCIe (mSATA / USB)
  • 1 x SIM (Push-Push)

I/O ports:

  • Network 4 x Intel GbE
  • USB: 3 x USB 2.0
  • COM: 2 x COM
  • Display: VGA & HDMI

Optional Modules: GPS, Bluetooth, PoE, WiFi, 4G LTE, Isolated COM,battery UPS, DI/DO, Video Input
Optional Accessories: *SATA Kit, VESA Mounting Kit
Power:

  • DC input : +12V
  • AC input : External adapter 100 / 240V
  • AC-DC 30W

OS Support:

  • Windows® 10 IOT (64bit), Windows® 8.1 (64bit), Windows® Embedded 8 Standard (64bit),
  • Windows® 7 (32/64bit), Windows® Embedded Standard 7 Runtime,
  • Ubuntu 14.10 above, Fedora 25 above, Debian 8 above, CentOS 7.3 above, Mint 18.1 above

Certification:  class A

Customs Tariff Nr. : 84715000
